Product Name:

Hardened Tool Steel Molding Insert for High-Volume Production

Material:

H13 Tool Steel (Vacuum-Hardened)

Specifications:

• Dimensions:
  • Length: 90 mm
  • Width: 60 mm
  • Height: 30 mm
  • Tolerance: ±0.02 mm
  • Tolerance Grade: IT6
• Surface Treatment:
  Nitriding and chrome-plated for extended durability
• Hardness:
  HRC 48-52
• Surface Roughness:
  Ra ≤ 0.2 μm
• Cooling Channels:
  Integrated for improved heat dissipation
• Applications:
  High-volume plastic molding for automotive components
• Temperature Resistance:
  Operates at molding temperatures up to 400°C
• Packaging:
  Anti-rust coated, vacuum-sealed, and foam-protected in wooden crates
• Lead Time:
  12-16 working days
