【Product Overview】
This 16mm Inspection Disk is a high-precision machined industrial component manufactured strictly according to official drawing (No.A3, 1:1 non-scalable scale). Crafted from premium AlMg4,5Mn (5083) aluminum magnesium alloy — a high-strength, corrosion-resistant rust-proof aluminum series — the disk features a smooth white powder coated surface for enhanced wear and corrosion protection. Fully compliant with DIN and ISO international industrial standards, it undergoes professional deburring and edge blunting processes, ensuring perfect dimensional accuracy and structural stability for various industrial inspection and mechanical matching scenarios.
【Key Specifications & Technical Parameters】
?
Product Size : 16mm (Inspection disk)
?
Material : AlMg4,5Mn (5083) Aluminum Magnesium Alloy (high strength, corrosion resistance)
?
Surface Treatment : White Powder Coated (wear-resistant, anti-corrosion)
?
Dimensional Unit : Millimeter (mm)
?
Drawing No. : A3 | Scale : 1:1 (Non-scalable)
?
Machining Process : Precision CNC machining, full dimensional calibration, professional deburring, edge blunting
?
Compliant Standards :
- Tolerance: DIN ISO 2768-fH (linear/angle tolerance, medium-high precision)
- Surface Quality: ISO 1302 (surface texture representation)
- Edge Treatment: ISO 13715 (workpiece edge processing)? Key Dimensional Features : Multiple arc/linear dimensions (R8.00, R10.00, R15.00, 80.50mm, 25.00mm, etc.) as per drawing
【Core Product Advantages】
?? Premium Material Performance
Made of AlMg4,5Mn (5083) aluminum magnesium alloy, featuring high tensile strength, excellent corrosion resistance and light weight, suitable for long-term use in various industrial environments.
?? Professional Surface & Edge Treatment
White powder coated surface for enhanced anti-scratch and anti-corrosion performance; all edges are deburred and blunted in accordance with ISO 13715, avoiding sharp edge damage and ensuring safe assembly and use.
?? Strict Precision & Standard Compliance
Follow DIN ISO 2768-fH precision tolerance for all dimensional processing, ISO 1302 surface quality standard, consistent with international industrial procurement requirements, zero assembly error.
?? Precision CNC Machining
Adopt advanced CNC machining technology for one-time forming, full dimensional inspection after processing, ensuring each product’s parameters are completely consistent with the drawing.
【Application Scenarios】
This 16mm precision inspection disk is widely applicable to various industrial fields, including:
- Industrial mechanical equipment inspection and calibration
- Precision instrument matching and positioning
- Automated production line detection components
- Mechanical spare parts for industrial inspection equipment
- Custom mechanical component matching for manufacturing industry
【Quality Control & Packaging】
? Strict Quality Inspection
- Raw material inspection: 100% material composition testing for AlMg4,5Mn (5083) alloy
- Processing inspection: Real-time dimensional monitoring during CNC machining
- Finished product inspection: Full dimensional calibration, surface quality and edge treatment inspection, compliance with DIN/ISO standards verification
? Secure Packaging
- Inner packaging: Anti-scratch plastic film + EPE foam (protect surface coating from damage)
- Outer packaging: Sturdy corrugated carton (shockproof, anti-pressure)
- Marking: Clear labeling of product specification, material, quantity and drawing number for easy identification and storage
【Why Choose Us】
We are a professional manufacturer of precision machined industrial components with strict adherence to international DIN/ISO standards. For this 16mm inspection disk, we use high-quality AlMg4,5Mn (5083) aluminum magnesium alloy and advanced CNC machining technology, with a complete quality control system from raw material selection to finished product delivery. We can also provide customized machining services according to your drawing requirements (different sizes, surface treatments, precision standards). Our products are widely supplied to global industrial manufacturers, with stable quality and on-time delivery as our core advantages.
【Inquiry Notice】
If you have any questions about product parameters, customization requirements, production cycle or bulk procurement prices, please contact our professional sales team. We will reply you within 24 hours and provide detailed technical support and exclusive quotation plans.
